Omschrijving
De Sirio New Vector 4000 is een hoogwaardig uitgevoerd basisantenne van aluminium (6063 T-832).
De antenne is standaard vanaf de fabriek afgesteld op de midden banden.
Electrical Data
Type: 3/4 ? coaxial J-pole
Frequency range: tunable from 27 to 28.5 MHz
Impedance: 50O
Radiation (H-plane): 360° omnidirectional
Polarization: vertical
Gain: 2 dBd, 4.15 dBi
Bandwidth @ SWR = 2: = 1400 KHz (120 channel)
SWR @ res. freq.: = 1.2
Max. power:
1000 Watts (CW) continuous
3000 Watts (CW) short time
Feed system / position: Gamma match / base
Connector: UHF-female
Mechanical Data
Materials: Aluminium, Steel, Nylon
Wind load / resistance: 329 N at 150 Km/h / 130 Km/h
Wind surface: 0.29 m²
Height (approx.): 8480 mm
Weight (approx.): 4700 gr
Mounting mast: Ø 35-42 mm
Packing dimensions LxWxH : 145 x 16 x 13 cm.
Packing weight: 5700 gr.
